ATV trailer full trailer for 3-ton firefighting robot

name:ATV trailer full trailer for 3-ton firefighting robot

detailed information息

3 ton fire robot trailer

Brand: Nangong, model: NGTT03BSM-21/30-4H, material: Q235 steel, load capacity: 3 tons, frame size: 3 * 2.1 meters, net weight: 1.2 tons, color: red and black;

Detailed technical requirements for a 3-ton fire robot trailer: (Specific implementation shall be based on the plan confirmed by both parties)

1. Load capacity of this vehicle: 3 tons;

2. Platform size: 3 meters in length and 2.1 meters in width;

3. Frame material: 8 # steel welded, 4mm thick patterned plate laid on the surface of the carriage platform;

4. Ladder: Two sets of overturned ladders are equipped at the rear of the car for the machine to climb on its own (specific size to be determined by the customer), and the surface of the ladder is welded with round steel to prevent slipping;

5. Guardrail: The front, left, and right sides of this vehicle are fixed square tube guardrails with a height of 200mm;

6. Outriggers: This vehicle is equipped with four mechanical outriggers around it, and the front traction frame is equipped with a set of universal wheels to support the vehicle in parallel during normal times;

7. Tires: This vehicle is equipped with 4 700-16 pneumatic tires, with a maximum single wheel load capacity of 1300KG and a speed of within 80km/h;

8. Limit device: Four 300MM long No. 8 channel steels are welded inside the carriage for equipment limit (specific dimensions provided by the customer);

9. Braking: Parking brake (handbrake, brake the first two wheels);

10. Shock absorption: Plate spring shock absorption (four wheels);

11. Rope tightening device: 3 rope tightening devices and binding hooks are equipped on both sides of the vehicle body;

12. Provide a connector and plug, and stick reflective stickers around the vehicle body;

13. Color: alternating red and black.

The 3-ton ATV trailer for fire robots is a long-term non-standard customization of Nangong vehicles, with good quality, excellent price, and fast delivery.

Application: ATV trailer for firefighting robots, fully mounted, with a speed of 60km/h。
